2.0AMP 500V 3 Pin Right Angle Header Connector For MP3 Pcb Double Row

2.0AMP 500V 3 Pin Right Angle Header Connector For MP3 Pcb Double Row

  • 2.0AMP 500V 3 Pin Right Angle Header Connector For MP3 Pcb Double Row
2.0AMP 500V 3 Pin Right Angle Header Connector For MP3 Pcb Double Row
Product Details:
Place of Origin: China
Brand Name: WCON
Certification: UL/SGS/ROHS
Model Number: 1240-12XXXXRXXXC0XX
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: negotiaiton
Packaging Details: tube packing
Delivery Time: 15~25Day
Payment Terms: T/T
Supply Ability: 800000pcs
Contact Now
Detailed Product Description
Plasitc High: H=4.0 Type: Double Row
Pitch: 2.0mm Color: Black
Port: Hong Kong
High Light:

2.0AMP Right Angle Header Connector

,

MP3 3 Pin Header Connector

,

Pcb Right Angle Header Connector

Right Angle Pin Header 2mm Pitch Connector , PA9T Black Double Row



Application range: 3 pins are widely used in monitors, digital cameras, MP3, MP4, PDA, computers, computer motherboards, mobile storage disks, card readers, security products, electricity meters, cordless phones, mobile phones, walkie-talkies, program-controlled switches, VCD, DVD , LCM/LED display modules, electronic toys, household appliances, etc. Provide the most reliable connection for board-to-board and wire-to-board.



Rated Current 2.0AMP
Contact Resistance 20mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material Brass
Contact Plating Au Or Sn over Ni
Insulator Material PA9T Black+30%GF UL94V-0 BK



Product Name: pin connector
features: the use of a wide range of environmental protection fireproof antioxidant strong conductivity, to be blocked in the circuit between the circuit or isolated, play bridge function, assume the current task or signal transmission.
product material: its material is brass wire, phosphorus copper wire, copper clad steel wire, pure copper wire, the surface of nickel plating, nickel plating.
A splice (or simply splice) is a type of electrical connector. Male headers consist of one or more rows of metal pins molded into a plastic base, typically 2.54 mm (0.1 in) apart, but are available in a variety of pitches. Male headers are cost-effective due to their simplicity. Female connectors are also sometimes called female receptacle headers, although male and female connectors are named in a variety of ways. Historically, plugs have sometimes been called "Berg connectors," but plugs are made by many companies.





2.0AMP 500V 3 Pin Right Angle Header Connector For MP3 Pcb Double Row 0



Right angle 2.0mm pitch double row 2*15P PA9T black gold flash ROHS.



WCON Pcb Pin Male Header Connector Single Row Header 2.00mm 1*22P 180ÃÆ’‚°DIPDrawing:pin header 1240-12XXXXRXXXC0XX.pdf
