| Place of Origin: | China |
| Brand Name: | WCON |
| Certification: | UL/SGS/ROHS |
| Model Number: | 1240-12XXXXRXXXC0XX |
| Minimum Order Quantity: | 1000pcs |
|---|---|
| Price: | negotiaiton |
| Packaging Details: | tube packing |
| Delivery Time: | 15~25Day |
| Payment Terms: | T/T |
| Supply Ability: | 800000pcs |
| Plasitc High: | H=4.0 | Type: | Double Row |
|---|---|---|---|
| Pitch: | 2.0mm | Color: | Black |
| Port: | Hong Kong | ||
| High Light: | PA9T Male And Female Header Pins,2mm Male And Female Header Pins,500V Dual Row Header Connector |
||
Right Angle Pin Header 2mm Pitch Connector , PA9T Black Double Row
Double Row 3 pin Header is widely used in display, digital camera, MP3, MP4, PDA, computer, computer motherboards, mobile storage disk, card reader, security products, electricity meter, wireless telephone, mobile phone, interphone, program-controlled switches, VCD, DVD, LCM/LED display module, electronic toys, household appliances etc.. Provide the most reliable connection for the plate to plate and the line to plate.
| Rated Current | 2.0AMP |
| Contact Resistance | 20mΩ Max |
| Withstand Voltage | 500V AC/DC |
| Insulation Resistance | 1000mΩ Min |
| Operation Temperature | ﹣40℃ to +105℃ |
| Contact Material | Brass |
| Contact Plating | Au Or Sn over Ni |
| Insulator Material | PA9T Black+30％GF UL94V-0 BK |
| Product Name: pin connector | ||||||||
| features: the use of a wide range of environmental protection fireproof antioxidant strong conductivity, to be blocked in the circuit between the circuit or isolated, play bridge function, assume the current task or signal transmission. | ||||||||
| product material: its material is brass wire, phosphorus copper wire, copper clad steel wire, pure copper wire, the surface of nickel plating, nickel plating. | ||||||||
| Application scope: 3 pin is widely used in display, digital camera, MP3, MP4, PDA, computer, computer motherboards, mobile storage disk, card reader, security products, electricity meter, wireless telephone, mobile phone, interphone, program-controlled switches, VCD, DVD, LCM/LED display module, electronic toys, household appliances etc.Pin headers are stiff metallic connectors that are soldered to a circuit board and stick up to receive a connection from a female socket. While pin headers (often called PH, or headers) are male by definition, female equivalents are also quite common, and we refer to them as female headers (FH) or header connectors. |
Right angle 2.0mm pitch double row 2*15P PA9T black gold flash ROHS.
Drawing:pin header 1240-12XXXXRXXXC0XX.pdf
