PA9T Greyish White 2.54 Pitch Box Header 90 Degrees Bend Pcb Header Connector

PA9T Greyish White 2.54 Pitch Box Header 90 Degrees Bend Pcb Header Connector

  • PA9T Greyish White 2.54 Pitch Box Header 90 Degrees Bend Pcb Header Connector
  • PA9T Greyish White 2.54 Pitch Box Header 90 Degrees Bend Pcb Header Connector
PA9T Greyish White 2.54 Pitch Box Header 90 Degrees Bend Pcb Header Connector
Product Details:
Place of Origin: China
Brand Name: WCON
Certification: UL/CUL/SGS/ROHS
Model Number: 3110-XXRG0BK00A1
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiation
Packaging Details: Tube Reel
Delivery Time: 15-25Day
Payment Terms: T/T
Supply Ability: 800000kpcs
Contact Now
Detailed Product Description
Fire Rating: UL94V-0 Colour: Greyish White
Purpose: Pecifications Of IDC Cable And Other Circuit Form: 90 Degrees
Production Process: Stamping Injection Molding
High Light:

male header connector

,

pcb header connector

PA9T Greyish white 2.54Ptch Box Header Connector 90 degrees bend





Current Rating 3.0AMP
Contact Resistance 20mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material Brass
Contact Plating Au or Sn over Ni
Insulator Material PA9T +30%GF( UL94V-0 )

PA9T Greyish White 2.54 Pitch Box Header 90 Degrees Bend Pcb Header Connector 0





Item name: Ejector Header
Product material: PA9T/LCP/PBT plating surface treatment: gold or tin plating
Application scope: it is mainly used in communication and electronic equipment and data by welding on the PCB board, connecting the corresponding specifications of IDC cable and other circuit designers need to be welded on a PCB board, connecting the corresponding specifications of IDC cable and other circuit designers need





1.27mm Pcb Female Header / 20 Pin Header Connector 180°DIP PPS 30%GF UL94V-0Drawing:3110-XXRXXBK00X1.pdf
