2.0mm Dual Row Female Header Connector H 6.35 180°DIP ADD Housing Signal transmission

2.0mm Dual Row Female Header Connector H 6.35 180°DIP ADD Housing Signal transmission

    • 2.0mm Dual Row Female Header Connector H 6.35 180°DIP ADD Housing Signal transmission
    • 2.0mm Dual Row Female Header Connector H 6.35 180°DIP ADD Housing Signal transmission
  • 2.0mm Dual Row Female Header Connector H 6.35 180°DIP ADD Housing Signal transmission

    Product Details:

    Place of Origin: China
    Brand Name: WCON
    Certification: UL/SGS/ROHS
    Model Number: 2263D-2XXSXXDYNTX

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000PCS
    Price: negotiaiton
    Packaging Details: Tube
    Delivery Time: 15~25Day
    Payment Terms: T/T
    Supply Ability: 800000kpcs
    Contact Now
    Detailed Product Description
    Product Features: Plastic Lined Mother Rated Voltage: 500V AC/DC
    Rated Current: 2.0AMP Product Use: Signal Transmission

    2.0mm Dual Row H=6.35 180°DIP ADD Housing Three layer plastic



    Current Rating 2.0AMP
    Contact Resistance 20mΩ Max
    Withstand Voltage 500V AC/DC
    Insulation Resistance 1000mΩ Min
    Operation Temperature ﹣40℃ to +105℃
    Contact Material phosphor Bronze
    Contact Plating AU over Ni
    Insulator Material LCP+30%GF UL94V-0



    Item name: female connector:

    1. product features: the use of a wide range of environmental protection, high temperature, fire resistance, oxidation resistance.



    2. product material: PA9T/PBT/ brass or phosphor bronze insulation material: plastic UL 94V-0.



    3. scope of application: widely used in electronics, electrical appliances, instruments in the general connection of the main components of the current or signal transmission. Usually with the needle supporting the use of a board to board connection. The utility model is matched with an electronic wiring harness terminal to form a board to wire connection.



    2.0mm Dual Row Female Header Connector H 6.35 180°DIP ADD Housing Signal transmission



      1.27mm Pcb Female Header / 20 Pin Header Connector 180°DIP PPS 30ï¼…GF UL94V-0Drawing:Female Header 2263D-2XXSXXDYNTX.pdf
