|Place of Origin:||China|
|Minimum Order Quantity:||1000PCS|
|Range Of Use:||Terminal To Form A Board To Wire Connection.||Number Of Pins To Be Produced:||02-40P|
|Type:||DIP||Operation Temperature:||﹣40℃ To +105℃|
2 spacing, three row inline female Header connector customization
Item name: female connector:
1. product features: the use of a wide range of environmental protection, high temperature, fire resistance, oxidation resistance.
2. product material: PA9T/PBT/ brass or phosphor bronze insulation material: plastic UL 94V-0.
3. scope of application: widely used in electronics, electrical appliances, instruments in the general connection of the main components of the current or signal transmission. Usually with the needle supporting the use of a board to board connection. The utility model is matched with an electronic wiring harness terminal to form a board to wire connection.
|Contact Resistance||20mΩ Max|
|Withstand Voltage||500V AC/DC|
|Insulation Resistance||1000mΩ Min|
|Operation Temperature||﹣40℃ to +105℃|
