| Gender: | Female | Port: | Hong Kong |
|---|---|---|---|
| Model NO: | 6200-X15MX15FXXXXX | Material: | PBT |
| Origin: | China | Brand: | WCON |
| High Light: | db15 female connector,9 pin d connector |
||
D-SUB on 15P Male Under 15P Female Right Angle Dual Row D-SUB Connector
| 1.Currenr Rating | 5.0AMP |
| 2.Contact Resistance | 25mΩ Max |
| 3.Withstand Voltage | 1000V AC/DC |
| 4.Insulation Resistance | 5000mΩ Min |
| 5.Operation Temperature | ﹣55℃ to +105℃ |
| 6.Contact Material | Brass |
| 7.Contact Plating | Au Or Sn over Ni |
| 8.Insulator Material | PBT+30%GF UL94V-0 |
| 9.Shell Material | Spcc Plating Ni Plated |
| 10.Rivet Harpoon | Brass Sn over Ni |
| 11.Screw | Brass,Plating Ni Plated |
| Product Name:D type D-SUB connector | ||
| 1. features: the use of a wide range of environmental protection fireproof antioxidant electrical conductivity and long service life force is strong. | ||
| 2. material: PBT (green, black, white) plus fiber 30% UL94V-0 contact body material: brass (C3604) | ||
| 3. scope of application: used for connecting a computer, communication, medical equipment, wire and cable, aviation, digital, machinery and equipment, game consoles and other integrated circuit package pins and printed circuit board. |
Drawing:D-SUB 6200-X15MX15FXXXXX.pdf
