Four Row H=10.5 1.27*2.54 Mm Pitch Box Header Connector straight PA9T black ROHS

China WCON ELECTRONICS ( GUANGDONG) CO., LTD certification
China WCON ELECTRONICS ( GUANGDONG) CO., LTD certification
I'm Online Chat Now

Four Row H=10.5 1.27*2.54 Mm Pitch Box Header Connector straight PA9T black ROHS

Four Row  H=10.5 1.27*2.54 Mm Pitch Box Header Connector  straight PA9T black ROHS
Four Row  H=10.5 1.27*2.54 Mm Pitch Box Header Connector  straight PA9T black ROHS Four Row  H=10.5 1.27*2.54 Mm Pitch Box Header Connector  straight PA9T black ROHS Four Row  H=10.5 1.27*2.54 Mm Pitch Box Header Connector  straight PA9T black ROHS Four Row  H=10.5 1.27*2.54 Mm Pitch Box Header Connector  straight PA9T black ROHS

Large Image :  Four Row H=10.5 1.27*2.54 Mm Pitch Box Header Connector straight PA9T black ROHS

Product Details:

Place of Origin: China
Brand Name: WCON
Certification: UL/CUL/SGS/ROHS
Model Number: 3141-XXSXXBK00X2

Payment & Shipping Terms:

Minimum Order Quantity: 1000pcs
Price: Negotiation
Packaging Details: Tube Reel
Delivery Time: 15-25Day
Payment Terms: T/T
Supply Ability: 800000kpcs
Detailed Product Description
Sample: Free Application: Power, Automobile, PCB, Microwave
Pitch: 1.27*2.54mm Insulation Resistance: 1000mΩ Min
Operation Temperature: ﹣40℃ To +105℃ Pins: 10~100P
High Light:

board to wire connectors

,

male header connector

1.27*2.54mm DIP H=10.5 Box Header Connector PA9T Brass Gold Flash Sample Free



Current Rating 1.0AMP
Contact Resistance 20mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material Brass
Contact Plating Au or Sn over Ni
Insulator Material PA9T +30%GF( UL94V-0 )





Product name: 1.27*2.54 BOX Header Connector

1. Product features: high temperature resistant to high voltage electrical conductivity

2. Box Header Connector material: PA9T/LCP/PBT, plating surface treatment: gold-plated or tin plating

3. Scope of application: Mainly suitable for data communication and electronic equipment and welding on the PCB board, connected to the corresponding specification of IDC ribbon cable and the other circuit designers need to circuit. And if current usually transmission control signal

Four Row  H=10.5 1.27*2.54 Mm Pitch Box Header Connector  straight PA9T black ROHS 0



1.27mm Pcb Female Header / 20 Pin Header Connector 180°DIP PPS 30ï¼…GF UL94V-0 Drawing:Box Header 3141-XXXSXXBK00XX.pdf
