Green Barrier Style Terminal Blocks , Feed Through / Din Rail Terminal Block

Green Barrier Style Terminal Blocks , Feed Through / Din Rail Terminal Block

  • Green Barrier Style Terminal Blocks , Feed Through / Din Rail Terminal Block
  • Green Barrier Style Terminal Blocks , Feed Through / Din Rail Terminal Block
Green Barrier Style Terminal Blocks , Feed Through / Din Rail Terminal Block
Product Details:
Place of Origin: China
Brand Name: WCON
Certification: UL/SGS/ROHS
Model Number: BH
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: negotiaiton
Packaging Details: PE packing
Delivery Time: 15~25Day
Payment Terms: T/T
Supply Ability: 800000pcs
Contact Now
Detailed Product Description
Delivery Way: DHL UPS TNT FEDEX Color: Green
Product Use: Industrial Automation Automata Product Name: Din Rail Terminal Block Connector
Highlight:

plug in terminal block connector

,

pluggable terminal block connector

Barrier Terminal Block din rail terminal blocks feed through terminal block







Current Rating 15A
Voltage Rating 300V
Contact Resistance 8milliohm Max
Withstand Voltage AC/DC 2500V
Insulation Resistance 1000Megohm Min
Screw Torque 4.4 lbf.in
Wire range 12AWG-30AWG
Housing Material PA66 UL94V-0
Screw Steel
Pin Block Brass
Cite Feet Brass
