M TYPE 2.54 Wafer Connector 2P Right Angle TYPE1 PA46 wire to board crimp style connectors

M TYPE 2.54 Wafer Connector 2P Right Angle TYPE1 PA46 wire to board crimp style connectors

  • M TYPE 2.54 Wafer Connector 2P Right Angle  TYPE1 PA46 wire to board crimp style connectors
  • M TYPE 2.54 Wafer Connector 2P Right Angle  TYPE1 PA46 wire to board crimp style connectors
M TYPE 2.54 Wafer Connector 2P Right Angle  TYPE1 PA46 wire to board crimp style connectors
Product Details:
Place of Origin: China
Brand Name: WCON
Certification: UL/SGS/R0HS
Model Number: WF2541-WRHXXE01
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: negotiation
Packaging Details: bag pack
Delivery Time: 15~25Day
Payment Terms: T/T
Supply Ability: 800000pcs
Contact Now
Detailed Product Description
Type: Right Angle Color: Natural
Plastic: PA46 Pitch: 2.54mm
Gender: Male Port: Hong Kong
High Light:

circuit board wire connectors

,

1.25 mm Pitch Connector

Item name: Wafer connector
product features: it makes the design and production process more convenient, more flexible, reduce production and maintenance costs, easy maintenance, easy to upgrade, improve the flexibility of the design
product material: (UL94V-0) PA9T, PA6T, PA46, PA66, etc.
scope of application: used in computer and peripheral equipment, communication products, test instruments, consumer electronics products, automotive industry, medical electronic products, the production of military and aerospace industry in which the device connecting the two active devices, current or signal transmission.



Current Rating 3.0AMP
Contactt Resistance 20mΩ Max
Withstand Voltage 1000V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣25℃ to +85℃
Contact Material Brass
Contact Plating Au Or Sn over Ni
Insulator Material PA66 or PA46 (UL94V-0)



WCON Pcb Pin Male Header Connector Single Row Header 2.00mm 1*22P 180°DIPDrawnig:wafer WF2541-WRXXX0X(1,2).pdf

M TYPE 2.54 Wafer Connector 2P Right Angle  TYPE1 PA46 wire to board crimp style connectors 1
