Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board

Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board

  • Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board
  • Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board
  • Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board
  • Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board
Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board
Product Details:
Place of Origin: China
Brand Name: WCON
Certification: UL/SGS/ROHS
Model Number: WF2547-1WZ04E01
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: negotiation
Packaging Details: Tray
Delivery Time: 15~25Day
Payment Terms: T/T
Supply Ability: 800000PCS
Contact Now
Detailed Product Description
Product Name: Wire To Board Connector Product Type: Wafer
Type: Male Plastic Material: PA66 White
Product Use: Pcb Connectors Wire To Board Custom Made: YES
Highlight:

circuit board wire connectors

,

1.25 mm Pitch Connector

2.54mm Right Angle SMT 4P Wire To Board Connector pcb connectors wire to board



Rated Current 3.0AMP
Contact Resistance 20mΩ Max
Withstand Voltage 1000V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣25℃ to +85℃
Pin Material Brass
Contact Plating Sn over Ni
Insulator Material Polyester(UL94V-0)
Standard PA66





Item name: Wafer connector
product features: it makes the design and production process more convenient, more flexible, reduce production and maintenance costs, easy maintenance, easy to upgrade, improve the flexibility of the design
product material: (UL94V-0) PA9T, PA6T, PA46, PA66, etc.
Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board 0
scope of application: used in computer and peripheral equipment, communication products, test instruments, consumer electronics products, automotive industry, medical electronic products, the production of military and aerospace industry in which the device connecting the two active devices, current or signal transmission.





Right Angle SMT 4P 2.54mm Pitch Connector , Pcb Connectors Wire To Board 1

WCON Pcb Pin Male Header Connector Single Row Header 2.00mm 1*22P 180°DIPWF2547-1WZXXXXXX1.pdf

Tag:

circuit board wire connectors,

1.25 mm Pitch Connector,

1.25 mm pitch connector
